Trafomatic Audio Premise

Premise
After releasing our Kaivalya monaural amplifiers, we were asked for an integrated stereo version with remote control. Retaining the Kaivalya's class A p/p output stage around a quartet of EL84/6BQ5 per channel driven from an ECC81, the Premise merely omits the complex and costly interstage transformer of the monos. With three inputs and 20 watts of minimum feedback tube power, the Premise not only inherits the white lacquer finish of the Kaivalya but the lion's share of its sonics.

Specifications:
Class of operation: Push Pull class A Triode/ Ultralinerar mode
?Tubes complement: 8 x EL84, 2 x ECC81
?Inputs: CD, Tuner, Aux
?Outputs: 4 , 8 ohms
?Input sensitivity: 0.85Vrms
?THD: 0.25% - 1W/1KHz?
Bandwidth: 10Hz (-1dB) - 50KHz (-3dB)
?S/N ratio: 88dB
?Input impedance: 100K
?Power consumption: 250VA
?Input voltage: 230V/50Hz (100-120-220-240V available on request)
?Size: 430 x 2900 x 1900mm
?Weight: 22kg
